Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery

1 Unit
MOQ
USD281/Unit
Price
Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery
Features Gallery Product Description Chat Now
Features
Specifications
Mesh Form: External Engaged
Tooth Flank: Straight Tooth
Tooth Curve: Involute
Power: Hydraulic
Applications: Machinery Manufacturing
Certification: CE, RoHS
Colour: Black
Rated Presure: 30MPa
Shell Material: Iron
Application Field: Mobile Device
Peculiarity: High Transmission Efficiency
Installation Mode: Flange Mounting
Media Compatibility: Hydraulic Oil
Maintenance: Periodic Inspection
Highlight:

pgp350 hydraulic gear pump

,

ce parker pgp350

,

rohs parker pgp350
Basic Infomation
Place of Origin: China
Brand Name: RUNHE
Certification: RohS
Model Number: PGP350A578KEAB1511
Document: PGP350 Hydraulic Pump_.pdf
Payment & Shipping Terms
Packaging Details: 45*32*30
Delivery Time: According to quantity
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 60000pcs/year
Product Description

High-Efficiency Parker PGP350 Series Hydraulic Pump Used in construction machinery

PGP350 gear pumps are made of solid cast iron, meet the assembly dimensions of ISO and UNI standards, and have convenient rear and side oil port designs to ensure long-term durability and high efficiency.
They are widely used in the hydraulic systems of chassis mobile vehicles such as dump trucks,vehicle-mounted cranes, aerial platforms, loading cranes and municipal vehicles.


Product Parameters

1.Heavy duty, cast iron, external gear pump .
2.Standardization, universalization , serialization design .
3.Displacement range:20.9ml/r -104.5 ml/r,
4.Max rated pressure:245bar,Intermittent:275bar,
5.Speed range:400-2400 RPM.

Speed
RPM
 		 Gear Width Output (gpm/lpm) and Inches (HP/kW)
1/2" 3/4" 1" 1-1/4" 1-1/2"
245bar 245bar 245bar 245bar 245bar
Flow Power Flow Power Flow Power Flow Power Flow Power
900
 		 15 8 24 12 33 17 42 21 52 25
4 11 6.4 17 8.8 22 11.2 28 13.7 33
1200 21 11 33 17 46 22 58 28 71 33
5.6 15 8.8 22 12.1 30 15.4 37 18.7 44
1500 28 14 43 21 59 28 74 34 89 41
7.3 18 11.3 28 15.5 37 19.5 46 23.6 55
1800 34 17 52 25 71 33 89 41 108 50
8.9 22 13.8 33 18.8 44 23.6 55 28.6 67
2100 40 19 62 29 84 39 105 48 127 58
10.6 26 16.3 39 22.1 52 27.8 65 33.6 78
2400 46 22 71 33 96 44 121 55 146 66
12.2 30 18.8 44 25.4 59 31.9 74 38.5 89


Speed
RPM
 		 Gear Width Output (gpm/lpm) and Inches (HP/kW)
1-3/4" 2" 2-1/4" 2-1/2"
225bar 210bar 190bar 175bar
Flow Power Flow Power Flow Power Flow Power
900
 		 61 27 70 28 79 29 89 30
16.1 36 18.6 38 21 39 23.4 40
1200 83 36 95 38 108 39 120 39
21.9 48 25.2 51 28.4 52 31.7 53
1500 105 45 120 47 136 49 151 49
27.7 60 31.8 63 35.9 65 40 66
1800 127 54 145 57 164 58 183 59
33.5 72 38.4 76 43.3 78 48.3 79
2100 149 63 171 66 192 68 214 68
39.3 84 45.1 89 50.8 91 56.6 91
2400 171 72 196 76 220 78 245 78
45.1 96 51.7 101 58.2 105 64.8 105

Flow: GPM/LPM     Power: HP/kW



Company Profile

Runhe Hydraulics is a professional supplier of Parker gear pumps, with premium quality, full models and reliable performance. We have rich industrial experience, support OEM service, cover global delivery and offer perfect after-sales for all hydraulic equipment needs

Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery 0

Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery 1

Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery 2

Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery 3

Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery 4

Parker PGP350 Series Hydraulic Gear Pump For Construction Machinery 5
